Product Code

Size

(inch)

SWL (WLL)

(ton)

Dimension (mm)

Weight

(kg)

A

B

C

D

E

F

TBBD-001

3/8x6

0.5

13

23

152

180

14

15

0.1

TBBD-002

1/2x6

1

16

29

152

188

18

20

0.3

TBBD-003

1/2x9

1

16

29

229

265

18

20

0.4

TBBD-004

1/2x12

1

16

29

305

341

18

20

0.6

TBBD-005

5/8x6

1.6

19

35

152

198

23

24

0.4

TBBD-006

5/8x9

1.6

19

35

229

275

23

24

0.6

TBBD-007

5/8x12

1.6

19

35

305

351

23

24

0.8

TBBD-008

3/4x6

2.4

23

43

152

208

28

27

0.7

TBBD-009

3/4x9

2.4

23

43

229

285

28

27

0.9

TBBD-010

3/4x12

2.4

23

43

305

361

28

27

1.2

TBBD-011

3/4x18

2.4

23

43

457

513

28

27

1.4

TBBD-012

7/8x12

3.3

28

52

305

371

33

32

1.6

TBBD-013

7/8x18

3.3

28

52

457

523

33

32

2.4

TBBD-014

1x6

4.5

32

59

152

228

38

37

1.3

TBBD-015

1x12

4.5

32

59

305

381

38

37

2.1

TBBD-016

1x18

4.5

32

59

457

533

38

37

2.7

TBBD-017

1x24

4.5

32

59

610

686

38

37

3.7

TBBD-018

1-1/4x12

6.9

38

67

305

385

40

46

2.5

TBBD-019

1-1/4x18

6.9

38

67

457

537

40

46

3.8

TBBD-020

1-1/4x24

6.9

38

67

610

690

40

46

4.6

TBBD-021

1-1/2x12

9.7

44

76

305

401

48

56

3.8

TBBD-022

1-1/2x18

9.7

44

76

457

553

48

56

5

TBBD-023

1-1/2x24

9.7

44

76

610

706

48

56

6.2

TBBD-024

1-3/4x18

12.7

54

92

457

570

56

66

7.9

TBBD-025

1-3/4x24

12.7

54

92

610

722

56

66

9.7

TBBD-026

2x24

16.8

60

105

610

738

64

75

13.5

TBBD-027

2-1/2x24

27.2

80

144

610

790

99

99

27.6

TBBD-028

2-3/4x24

34

80

144

610

790

99

99

27.6
